co2 laser power supply

Input voltage

220V/110V

Colour

Black

Responding speed

≤1ms

Operating Voltage

18KV

Rated power

500W

Power supply

6-24MA

Single package size

43*29*22cm

Condition

New

Output current

36mA

Effectiveness

91%

AC input voltage

AC220V or AC110V

DC input voltage

DC300V or DC150V

AC input frequency

47 ～ 440Hz

Voltage output

35KV

Maximum current

23mA (depending on the laser tube of different manufacturers)

Overcurrent protection

130% of maximum current

Open circuit protection

Yes (short time)

structure

Fan cooling

High-level control voltage range

≥3V

Low-level control voltage range

≤0.8V

input Output

AC1500V1min≤10mA

Insulation resistance

≥50MΩ (DC500V)

Full load 60 ℃ high temperature test time

12 hours

7 seconds on / off power test

500 times

Ground leakage current

≤1mA (AC220V) ≤0.5 mA (AC110V)

MTBF

≥30,000hours
